Goomax 836 kWh Outdoor Storage Cabinet

A water-cooled outdoor cabinet with explosion-proof, early-warning fire protection. Goomax says the footprint saves 51% of area, and lifting or forklift handling cuts installation time.

Goomax 836 kWh Outdoor Storage Cabinet

836 kWh · 1331.2 V · water-cooled outdoor

A water-cooled outdoor cabinet with explosion-proof, early-warning fire protection. Goomax says the footprint saves 51% of area, and lifting or forklift handling cuts installation time.

Specifications

BrandGoomax
Configuration2P416S · 314 Ah cells
Charge / discharge rate0.5P / 0.5P or 0.25P / 0.25P
Rated DC voltage1331.2 V
Rated energy836 kWh
ProtectionIP54 (battery compartment IP55 · pack IP67)
Dimensions (W × D × H)1500 × 2400 × 2372 mm (without lifting ring)
WeightUnder 8.2 t
DeploymentUp to 6 in parallel (5 MWh); suits 90% of road transport
CertificationsUN38.3 · IEC 62619 · IEC 62477 · IEC 61000 · IEC 60730; IEC 63056 in progress
DatasheetDatasheet

Price on request. Request a quote
